Omni-Bus is a distributed control system for lights, shades, fans, shutters, pumps, and more. Utilizing the worldwide DIN rail standard for mounting, Omni-Bus controls CFL, LED, electronic low voltage, Halogen, and incandescent lighting. Output devices are rated for 110/220/240V 50-60Hz markets unless otherwise noted. All wall stations are 24VDC and below. Modular Omni-Bus components can be located where needed to save wiring and installation costs. Elegant, multi-button programmable wall stations eliminate the expense of in-wall high voltage wiring to multi-way switches.
CHANNEL SWITCH INTERFACE MODULE – 114A00-1
Used to accommodate any shape and style momentary contact switch
Connect up to six momentary contact switches to the bus and operate them as if it were an Omni-Bus Wall Station, with all of the same functionality
Also supports up to six two-lead bi-color or single color LED indicators, one for each switch
Features control for on/off, dimming, brightening, and scene control, configurable operating modes, and can be linked to a Leviton Omni or Lumina controller
Bus side supply voltage: 15-24VDC (via bus network cable)
Bus side supply current: 40mA maximum (without 12VDC
output consumption)
Auxiliary Output voltage: 12VDC @ 100mA max
Ambient Temperature: 0 – 40 ºC (32 – 104 ºF)
Ingress Protection: IP20
Dimensions: 46mm x 50mm x 21mm
LED drive current: 5mA maximum per LED
Switch input maximum contact resistance: 1kohm
Maximum recommended switch input cable length:
10m (33 feet)
All modules are CE, FCC, UL (ETL), SASO, and C-Tick approved
Leviton Part Number: OB141
